Fazcorp

6A DC Circuit Breaker 2-Pole

6A DC Circuit Breaker 2-Pole

Regular price $32.95 NZD
Regular price Sale price $32.95 NZD
Sale Sold out
Tax included. Shipping calculated at checkout.
Default

This DC 2-pole Mini Circuit Breaker is Rated for 6 Amps, is non polarised and is 35mm din rail mountable for easy installation.

Specifications:

Rated Current: 6A
Rated Voltage: 550VDC
IP Rating: IP20
Tripping Characteristics: C Curve
Mechanical Life: 20,000
Maximum Cable Cross Section: 35mm2
Rupturing/Breaking Capacity: 6KA
Working Temperature: -20 to +70 Degrees Celsius
Relative Humidity: <95%
Test Standards: EN/IEC60947-1, EN/IEC60947-2
