SRNE Inverter 12V 3kW

Inverter Features:

• High Frequency 12V 3kW pure sine wave inverter with high conversion efficiency, low losses and low harmonic distortion rate
• RCD protection for added safety during earth faults
• Two AC outputs and one AC input for bypassing with a back up power supply i.e generator
• Built-in Bluetooth for real-time monitoring of inverter operation of inverter parameters through the mobile App SRNE
• Compatible with WF-1 wifi module for remote monitoring
• Compatible with SRNE Master Control Unit
• CAN function with RV-C Protocols

Inverter Specifications:

• Battery Voltage: 12VDC
• Input Voltage Range: 10.8-16.0VDC
• Rated Power: 3000W
• Surge Power: 6000W
• Waveform: Pure sine wave 50Hz
• AC Voltage Regulation: 230VAC
• Rated Output Efficiency: 87%
• Inverter Efficiency(Peak): 92% (30% Load)
• No Load Power Consumption: <16W
• THD: <4% (Resistive Load)
• Cooling:Neutral Cooling + Intelligent Fan

Bypass Mode:

• AC Input Voltage: Single Phase 180VAC-265VAC
• AC Input Frequency: 45-65Hz
• Rated Input Current: 25A

Dimensions (mm): 453*249*120
Weight: 8.3 kgs

Humidity: 5% to 95% RH(Non-condensing)
Operating Temperature: 0°C-60°C
Warranty: 2 years

Certification: IEC62109-1/2, IEC61000-6-2/4, SAA Approved
