MPPT solar charge controllers are programmed with a Maximum Power Point Tracking algorithm that allows the solar charge controller to track/calculate the maximum power output of a solar panel or solar array at any given time to a 99% rate of accuracy.
Due to the accuracy of the MPPT algorithm and the built in DC-DC converter, our MPPT solar charge controllers have a conversion efficiency of up to 98% for converting the solar energy into usable energy for charging the battery or supplying solar power directly to loads automatically when the battery is full.
The built in DC-DC power converter steps down the voltage from the solar panel to match the battery voltage, while transforming the surplus voltage into current. This method is up to 40% more efficient compared with the conventional P.W.M(Pulse Width Modulation) method.
The self-consumed power for the solar charge controller has been designed to be as low as 0.7W-1.2W resulting in minimal impact or power drain on your system.
Our MPPT solar charge controllers are compatible with all battery types, the battery charging parameters can also be customized.
A temperature sensor is supplied with each unit for monitoring battery temperature to help increase battery life and for extra safety.
System Voltage: 12/24V/36V/48V
Maximum Solar Open Circuit Voltage (V.O.C) : 150VDC
Maximum Solar Voltage (V.M.P) : 120VDC
DC-DC Conversion Frequency: 40kHz
Solar Input power:
12V Battery Bank: 800 Watts
24V Battery Bank: 1600 Watts
36V Battery Bank: 2400 Watts
48V Battery Bank: 3200 Watts
Rated Charge current: 60Amps
Rated Controller Load Output Current: 20Amps
Operating Temperature: -35 - +45 Degrees Celsius
Protection Degree: IP32
Size: 285mm x 205mm x 93mm
Warranty: 5 Years
